Commercial Led Monitor 75” Tr3dj-b Series Ips Uhd Ir Multi Touch

SMOOTH TOUCH & WRITING EXPERIENCE
Multi Touch
The TR3DJ series can have up to 20 points of touch simultaneously. This function offers a lifelike board touch experience and makes collaboration easier.

Enhanced Visibility with Low Parallax
With 1mm gap between the screen and tempered glass, which supports low parallax, The TR3DJ series can offer precise touch and excellent writing experience.

Dual Pen & Dual Color
The dual pens allow for two colors to be used at the time to write or draw.

Easy Writing Experience
The TR3DJ series allows you to write and annotate on virtually any input source.

Air Class
With Air Class you can connect up to 30 students. It offers interactive meetings for mobile devices on the same network, providing a variety of tools such as voting, answering, and sharing project texts. Air Class is easily installed from the TR3DJ's main toolbar.

Built-in OPS Slot
The TR3DJ series supports Open Pluggable Specification (OPS) slots, allowing you to easily and conveniently mount OPS device to the back of the digital board without the hassle of connecting to an external device.

ScreenShare Pro
ScreenShare Pro enables you to show up to six shared screens in real-time. It also allows users to share via Chromecast or with Apple device mirroring on the same network. This software can be used on IOS, Mac, Windows, Android, Chrome OS.

Bluetooth Connectivity
TR3DJ supports Bluetooth wireless connections to various devices such as speakers, a mouse or a keyboard. This is great for building a hybrid environment so that online and offline meetings and classes can proceed smoothly.

Web Browser
The TR3DJ series supports an embedded web browser, so you can search the web easily and quickly, without connecting to an external tablet or computer.

USB Block
USB Block Mode is a security measure that helps prevent data from being copied to unauthorized devices, which is essential for being used in spaces where security is critical.

PANEL
Screen Size 75”Panel Technology IPS
Back Light Type DirectAspect Ratio 16:9
Native Resolution 3,840 x 2,160 (UHD)Brightness (Typ., cd/ METRE SQUARE, w/ Protection Glass) 330
Contrast Ratio 1,100:1Viewing Angle (H x V) 178 x 178
Response Time 8ms (G to G)Life Time (Typ.) 30,000 Hrs (Min.)
Operation Hours 16 HrsOrientation Landscape
CONNECTIVITY
(Input) Video / Audio HDMI (3), RGB/Audio In(Input) External Control RS232C In
(Input) USB USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update), USB 3.0 (3), Touch Out(USB2.0,B Type) (2)(Output) Video / Audio HDMI (1), Optical Output/Audio Out
MECHANICAL SPECIFICATION
Bezel Color BlackBezel Width (Off Bezel) Top/Right/Left:17.7mm, Bottom:45.7mm
Monitor Dimension (W × H × D) 1,709 × 1,020 × 86 mmWeight (Head) 53kg
Carton Dimensions (W x H x D) with pallet 1,950 × 1,266 × 285 mmPacked Weight 85kg
Handle YesVESA Standard Mount Interface 800 x 400
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°COperation Humidity 10% to 80%
POWER
Power Supply 100-240V~, 50/60HzPower Type Built-In Power
Power Consumption (Typ. / Max.) 175/294 W
SOUND
Speaker Built in 24W (12W + 12W)
STANDARD(CERTIFICATION)
Safety CB/NRTLEMC FCC Class "A"/CE
ErP/Energy Star Yes (EU Only)/No
MEDIA PLAYER COMPATIBILITY
OPS type compatible Yes
ACCESSORY
Basic Power Cord 3 M1, USB Cable (Type A-Type B) 5 M1, HDMI Cable 3 M1, Writing Pen2pcs, User Manual, QSG, Carton Box, Remote Control
SPECIAL FEATURE
Embedded Writing Software Yes
TOUCH SPECIFICATIONS
Touch type IRAvailable object size for touch Ø3mm↑
Response Time 60ms↓ (Android)/100ms↓ (Windows)Accuracy 1.5mm
Interface USB 2.0Protection Glass Thickness 4T (Anti-Glare)
Protection Glass Transmission 87%Operating System Support Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
Multi touch point Max 20 points/Max 10 writing
