Finder Pro TV Signal Finder Meter -S/S2/S2X/T/T2/C

Overview:

GTMEDIA Finder Pro is a -S2X/S2/S/T2/T/C/ATSC-C and MPEG-2/4 H.264/H.265 (10 bit) compliant handheld combo meter. With its compact size, lightweight design, intuitive user's interface, long battery operational hours and rich feature set, the signal finder meter provides all functions needed for installation and verification of digital TV service, antenna signal and cable signal to residential homes or multi-dwelling units.



Features:

*4.3 Inch High Definition TFT LCD Screen

*Fully -S2X/S2/S/T2/T/C/ATSC-C, MPEG-2/MPEG-4 compliant

*Support H.264/H.265(10 Bit) Hardware decoding

*Digital measuring device for signal strength and quality

*Support Loop Search

*Constellation analyzer

*Spectrum analyzer

*Supports scan of Auto, Blind, Manual or NIT

*Sound for Locking Signal

*Auto Calculate Angle of AZ,EL

*Support DISEQC 1.0/1.1/1.2, Unicable, 0/22kHz Tone

*Speaker Integrated

*Support both AV out and AV in

*Support both HD out

*Support AHD camera input

*Support compass function

*Support real-time display, with low reminder

*Support Youtube for USB WiFi 2.4G

*LNB short protect

*7.4V/4000mAh Li-ion Battery Included

*Software upgrade via USB port

*Easy to carry



Specifications:

Connector Type: F Type

Input Frequency: 950 to 2150 MHz

Signal Input Level: ‐65~‐25dBm

Band Switch Control: 22KHz

LNB Supply: 13V/18V, Max 350mA

Demodulation Type: -S2 QPSK, -S2 QPSK/8PSK/16APSK/32APSK,

-S2X QPSK/8PSK/16APSK/32APSK/64APSK

Symbol Rate: 2

Key Features

x4.3 Inch High Definition TFT LCD Screen
xFully -S2X/S2/S/T2/T/C/ATSC-C, MPEG-2/MPEG-4 compliant
xSupport H.264/H.265(10 Bit) Hardware decoding
xDigital measuring device for signal strength and quality
xSupport Loop Search
xConstellation analyzer

What's In the Box

1 x Finder Pro,1 x AV Cable,1 x Adaptor,1 x User Manual (EN/DE/FR/ES/IT/PO)
