Product Details

Note: With an Inbuilt solar charger. All you need to do is plug in your solar panel terminals and batteries. It is all set for work! We are proud of this product. Tested.

Product Parameters

• Input Voltage (DC) 24 Volts DC
• Input Nominal Voltage 240 Volts AC
• Input Voltage Range 154 - 265 Volts ( for AC Supply Model) While 184-264 ±3Volts (UPS Model)
• Input Frequency 50-60Hz Auto Sensing


• Output Voltage 220 Volts AC
• Output Frequency 50/60 Hz
• Output Waveform Pure Sign Wave
• Output Transfer Time (AC to DC) < 8ms
• Output Transfer Time (DC to AC) <8ms
• Output Voltage Regulation ±10%
• Output Bypass Mode Yes
• Output Saver Mode Yes
• Output Efficiency >98%


• Input Protection Yes: Circuit Breaker
• Output Protection Yes: Circuit Breaker


• Battery Type AGM Deep Cycle | Gel Up to 500AH | Tubular Battery
• Battery AC Charging Current 30 Ampere
• Battery Low-Level Disconnect (Selectable) 20 Volts | 21 Volts (21 Volts recommended for extended battery life; your battery replacement time will be much longer)


• Solar Charge PWM Controller Voltage 30-66 Volts DC
• Solar Charge Maximum PV Array Power 1200 Watts (Do not exceed. Please provide an earthing connection for the Solar Panels to protect your system from Lightning Storm High Voltage Surges during rain.)
• Solar Charge Maximum PV Display Open Circuit Voltage 60 Volts PWM
• Solar Charrge Maximun PV Solar Charge Current 50 Ampere


• LCD Indicator Status AC Input Voltage, AC Input Frequency, PV Voltage, PV Current, Output Voltage, Output Current, Output frequency and more.
• LED Indicator Status AC line-in: Green | Inverter: Green | Charging: Yellow | Fault-Alarm: Red


• Low Battery Alarm Audible Alarm: Beep Every 5 Seconds
• Overload Alarm Audible Alarm: Continuous Beeps
• Fault Alarm Audible Alarm: Continuous Beeps



• Environmental Temperature 0-46 degrees Celcius

• Humidity -10 degrees - ~90 degrees Celcius Non-Condensing

• Accustic Noise(dB) >55(dB)

• Size(Lenght*Breath*Hiegth) (mm) 454mm * 243mm * 390mm

• Packaging (Lenght*Breath*Hiegth) (mm) 464mm * 253mm * 401mm

• Weight (Kg) 17kg

• Automatic Generator Start-up Signal Yes
• DC Start and Automatic Self-Diagnostic Function Yes
• High-Efficiency Energy Conservation Mode: “Power Saving Mode” Yes
• Auto Restart Yes
• Smart Battery Charger for Optimal Performance Yes
• Battery Charging Current Selection Option Yes

Materstanresources offers free product and installation Technical Advice.
